SFKR

STOCK ITEM
Match with Screw shaft: SCR.
Standard nuts are with scrapers. Other types on request.

All other dimensions in mm
Download PDF
Technical Drawing
Designation Select all Lead Time * Dynamic load ratings Ca Static load ratings C0a
2 1110 N 2240 N
Compare
Get quote
1 1610 N 4030 N
Compare
Get quote
1 2430 N 5690 N
Compare
Get quote
1 3340 N 9060 N
Compare
Get quote
1 3540 N 10530 N
Compare
Get quote

* Green: Stock item, normally immediate shipment. Blue: Contact us for delivery time.

Technical Drawing
Designation Select all d0 x Lead A B L D H
6 x 1 24 3,50 15 12 16
Compare
Get quote
8 x 1 27 4 16 14 18
Compare
Get quote
10 x 2 35 5 28 18 22
Compare
Get quote
12 x 2 37 5 28 20 24
Compare
Get quote
14 x 2 40 6 23 21 26
Compare
Get quote
Technical Drawing
Designation Select all X W
3,40 18
Compare
Get quote
3,40 21
Compare
Get quote
4,50 27
Compare
Get quote
4,50 29
Compare
Get quote
5,50 31
Compare
Get quote
Designation Select all Ball diameter Turns x circuits
0,80 1 x 3
Compare
Get quote
0,80 1 x 4
Compare
Get quote
1,20 1 x 3
Compare
Get quote
1,20 1 x 4
Compare
Get quote
1,20 1 x 4
Compare
Get quote
  • STOCK ITEM
    Support unit for end of ball screw machined accordingly
  • STOCK ITEM
    Support unit for end of ball screw machined accordingly
  • STOCK ITEM
    Support unit for end of ball screw machined accordingly
  • STOCK ITEM
    Support unit for end of ball screw machined accordingly
  • STOCK ITEM
    Ball nut, miniature, cylindrical with thread for right lead (SR) screw
